FLORA LED 200 D120 Universal 380V
model is discontinued
model is discontinued
FLORA LED 200 D120 Universal 380V
225 Wluminaire power
28300 lmlight flow
126 lm/Wenergy efficiency
code1338000030
color temperature3000 K
beam angleD120
options
свернуть все
illuminatingelectricalconstructionalcommon
light flow
28300 lmflickering factor
<1%energy efficiency
126 lm/Wbeam angle
D120color temperature
3000 Klight source type
LEDemission color
Белыйilluminating
light flow
28300 lm
flickering factor
<1%
energy efficiency
126 lm/W
beam angle
D120
color temperature
3000 K
light source type
LED
emission color
Белый
electrical
electric shock protection
I
luminaire power
225 W
power factor
> 0,98
maximum cross-section of the connected cable
2.5 mm2
supply voltage
230 V
constructional
length
1600 mm
width
80 mm
height
71 mm
material
Алюминий
housing color
Металлик
climatic performance
УХЛ3.1*
installation length
1600 mm
weight
4.2 kg
ingress protection (IP)
IP54
shock resistance (IK)
IK02/0,2 Дж
common
code
1338000030
ETIM class
Светильник для освещения высоких пролетов (хайбей)
energy efficiency class
A+
service life
50 000 h
temperature range
от +5 до +35 C
model files
model files
photometric files
сертификаты
photometric files
ies107.1 kB
jpg79.8 kB
ldt66.3 kB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20111.6 mB
Declaration of Conformity EAEU TR 037/2016595.1 kB
Fire Safety Certificate2.5 mB
