VIZOR LED 30W D15 827 RAL7022

VIZOR LED 30W D15 827 RAL7022
28 Wluminaire power
2100 lmlight flow
75 lm/Wenergy efficiency
code1717000110
beam angleD15
color temperature2700 K
weight4.4 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
75 lm/W
color rendition index (CRI)
>80
light flow
2100 lm
flickering factor
<5%
beam angle
D15
color temperature
2700 K
light source type
LED
emission color
Белый
illuminating
energy efficiency
75 lm/W
color rendition index (CRI)
>80
light flow
2100 lm
flickering factor
<5%
beam angle
D15
color temperature
2700 K
light source type
LED
emission color
Белый
electrical
luminaire power
28 W
electric shock protection
I
starting current pulse time
350 µs
rated supply voltage, alternating current
230 V
supply voltage
230 V
starting current
50 A
maximum cross-section of the connected cable
2.5 mm2
supply voltage, direct current
142-431 V
supply voltage, alternating current
90-305 V
power factor
> 0,95
constructional
climatic performance
УХЛ1*
fire safety class
П-ІІІ
width
295 mm
height
64 mm
installation length
200 mm
housing color
Серый
lamp socket
LED
number of lamps
1
ballast
Драйвер
length
335 mm
material
Алюминий
ingress protection (IP)
IP66
shock resistance (IK)
IK07/2 Дж
weight
4.4 kg
common
code
1717000110
warranty
36 month
energy efficiency class
A
temperature range
от -40 до +40 C
service life
50 000 h
ETIM class
Прожектор / Светильник направленного света
model files
model files
photometric files
ies31.4 kB
jpg80 kB
ldt16.3 kB
documents
passport3.4 mB
сертификаты
Russian origin278.3 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20111.2 mB
Declaration of Conformity EAEU TR 037/2016505.1 kB
photometric files
ies31.4 kB
jpg80 kB
ldt16.3 kB
documents
passport3.4 mB
сертификаты
Russian origin278.3 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20111.2 mB
Declaration of Conformity EAEU TR 037/2016505.1 kB
