TETRA LED 20W D12 730 SL
TETRA LED 20W D12 730 SL
22 Wluminaire power
1700 lmlight flow
77 lm/Wenergy efficiency
code1100100010
beam angleD12
color temperature3000 K
weight2.3 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
77 lm/Wcolor rendition index (CRI)
>70light flow
1700 lmflickering factor
<40%beam angle
D12color temperature
3000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
77 lm/W
color rendition index (CRI)
>70
light flow
1700 lm
flickering factor
<40%
beam angle
D12
color temperature
3000 K
light source type
LED
emission color
Белый
electrical
luminaire power
22 W
electric shock protection
I
rated supply voltage, alternating current
230 V
supply voltage
230 V
starting current
25 A
maximum cross-section of the connected cable
1.5 mm2
supply voltage, alternating current
220-240 V
power factor
> 0,90
constructional
climatic performance
УХЛ1*
fire safety class
П-ІІІ
width
100 mm
height
204 mm
installation length
53 mm
housing color
Металлик
lamp socket
LED
number of lamps
1
ballast
Драйвер
length
136 mm
material
Алюминий
ingress protection (IP)
IP65
shock resistance (IK)
IK02/0,2 Дж
weight
2.3 kg
common
code
1100100010
warranty
36 month
energy efficiency class
A
temperature range
от -20 до +40 C
service life
50 000 h
ETIM class
Настенно-потолочный светильник
model files
model files
CAD/BIM files
photometric files
documents
сертификаты
CAD/BIM files
model 3dMax1.2 mB
photometric files
ies1.9 kB
jpg118.2 kB
ldt1.8 kB
documents
passport1.2 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
