RADO 2x07 BL D45 3000K (with driver)
.jpg&w=1920&q=100)
.jpg&w=1024&q=75)
RADO 2x07 BL D45 3000K (with driver)
16 Wluminaire power
1400 lmlight flow
88 lm/Wenergy efficiency
code1278000440
color temperature3000 K
beam angleD45
performance factor100
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
88 lm/Wcolor rendition index (CRI)
>80light flow
1400 lmflickering factor
<5%beam angle
D45color temperature
3000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
88 lm/W
color rendition index (CRI)
>80
light flow
1400 lm
flickering factor
<5%
beam angle
D45
color temperature
3000 K
light source type
LED
emission color
Белый
electrical
starting current pulse time
2.28 µs
electric shock protection
II
luminaire power
16 W
supply voltage
230 V
power factor
> 0,95
maximum cross-section of the connected cable
2.5 mm2
rated supply voltage, alternating current
230 V
starting current
43 A
constructional
length
203 mm
width
110 mm
height
85 mm
installation length
185 mm
installation width
100 mm
weight
0.53 kg
ingress protection (IP)
IP20
shock resistance (IK)
IK02/0,2 Дж
climatic performance
УХЛ4*
fire safety class
П-ІІІ
material
Алюминий
housing color
Черный
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
warranty
36 month
temperature range
от 0 до +40 C
service life
50 000 h
energy efficiency class
A
ETIM class
Прожектор / Светильник направленного света
code
1278000440
model files
model files
CAD/BIM files
photometric files
documents
сертификаты
CAD/BIM files
model 3dMax1.7 mB
photometric files
ies107.1 kB
jpg76.7 kB
ldt50.5 kB
documents
passport1.5 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20111.2 mB
Declaration of Conformity EAEU TR 037/2016583.2 kB
Fire Safety Certificate1.7 mB
accessories
LINE PRISM SPOTLIGHT 06-18W0.05kgarticle: 2701002170
SQ PRISM SPOTLIGHT 06-18W0.005kgarticle: 2701002140
HONEYCOMB Spotlight 07-18W0.05kgarticle: 2701002060
