PROFILE 60H S LED 1500 WH IP54/IP20 4000K SET
PROFILE 60H S LED 1500 WH IP54/IP20 4000K SET
22 Wluminaire power
2200 lmlight flow
100 lm/Wenergy efficiency
code
4248000040
color temperature
4000 K
beam angle
D120
performance factor
100
- main page
- catalog
- by product type
- interior lighting
- continuous-row systems
- custom
- from 50 mm to 80 mm
- PROFILE SYSTEM
- PROFILE 60H S LED 1500 WH IP54/IP20 4000K SET
options
свернуть все
illuminatingelectricalconstructionalemergencycommon
energy efficiency
100 lm/Wcolor rendition index (CRI)
>80light flow
2200 lmflickering factor
<1%beam angle
D120color temperature
4000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
100 lm/W
color rendition index (CRI)
>80
light flow
2200 lm
flickering factor
<1%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,95
luminaire power
22 W
electric shock protection
I
supply voltage
230 V
maximum cross-section of the connected cable
1.5 mm2
constructional
length
1500 mm
width
60 mm
height
120 mm
installation length
1514 mm
installation width
60 mm
weight
2.2 kg
ingress protection (IP)
IP54/IP20
shock resistance (IK)
IK02/0,2 Дж
climatic performance
УХЛ4
fire safety class
П-ІІІ
material
Алюминий
housing color
Белый
mounting type
lamp socket
LED
number of lamps
1
ballast
Драйвер
Type roof
emergency
emergency power supply
Нет
common
temperature range
от 0 до +40 C
service life
50 000 h
ETIM class
Настенно-потолочный светильник
warranty
36 month
energy efficiency class
A+
code
4248000040
model files
model files
documents
сертификаты
documents
passport310.3 kB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/2011528.7 kB
Declaration of Conformity EAEU TR 037/2016533.3 kB
