PROFILE 60L P DR LED (1400) BL 4000K MED (low lumen)

PROFILE 60L P DR LED (1400) BL 4000K MED (low lumen)
17 Wluminaire power
1450 lmlight flow
85 lm/Wenergy efficiency
code1248004700
color temperature4000 K
beam angleD120
performance factor100
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
85 lm/W
color rendition index (CRI)
>80
light flow
1450 lm
flickering factor
<1%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
illuminating
energy efficiency
85 lm/W
color rendition index (CRI)
>80
light flow
1450 lm
flickering factor
<1%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
starting current pulse time
250 µs
electric shock protection
I
maximum number of luminaires in a line
23
luminaire power
17 W
supply voltage
230 V
power factor
> 0,96
maximum cross-section of the connected cable
2.5 mm2
rated supply voltage, alternating current
230 V
rated supply voltage
230 V
starting current
25 A
constructional
length
1410 mm
width
73 mm
height
85 mm
installation length
1220 mm
weight
3.7 kg
ingress protection (IP)
IP20
shock resistance (IK)
IK02/0,2 Дж
climatic performance
УХЛ4*
fire safety class
П-ІІІ
material
Алюминий
housing color
Черный
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
warranty
60 month
temperature range
от +5 до +35 C
service life
50 000 h
energy efficiency class
A
ETIM class
Светильник подвесной
code
1248004700
model files
model files
photometric files
ies263.2 kB
jpg116 kB
ldt165.9 kB
documents
passport1.2 mB
сертификаты
Russian origin287.1 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20112 mB
Declaration of Conformity EAEU TR 037/2016535.9 kB
Fire Safety Certificate2.5 mB
photometric files
ies263.2 kB
jpg116 kB
ldt165.9 kB
documents
passport1.2 mB
сертификаты
Russian origin287.1 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20112 mB
Declaration of Conformity EAEU TR 037/2016535.9 kB
Fire Safety Certificate2.5 mB
