OREOL SEMI FLD/P (1250) 840 BK
OREOL SEMI FLD/P (1250) 840 BK
40 Wluminaire power
3400 lmlight flow
85 lm/Wenergy efficiency
code1813001960
color temperature4000
beam angleD120
performance factor100
options
свернуть все
electricalconstructionalcommonilluminating
electric shock protection
Istarting current
25 Astarting current pulse time, µs
85 mksrated supply voltage, alternating current
230 Vrated supply voltage, direct current
230 Vsupply voltage, alternating current
176-264 Vsupply voltage, direct current
176-280 Vluminaire power
40 Wpower factor
> 0,95supply voltage
230 Velectrical
electric shock protection
I
starting current
25 A
starting current pulse time, µs
85 mks
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
supply voltage, alternating current
176-264 V
supply voltage, direct current
176-280 V
luminaire power
40 W
power factor
> 0,95
supply voltage
230 V
constructional
maximum cross-section of the connected cable, sq. mm
2.5
ingress protection (IP)
IP40
material
Алюминий
housing color
Черный
length, mm
1250 mm
width, mm
625 mm
height, mm
60 mm
weight
3.7 kg
climatic performance
УХЛ4*
installation length, mm
1050 mm
installation width, mm
525 mm
shock resistance (IK)
IK02/0,2 Дж
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
ETIM class
Светильник подвесной
warranty
36 month
temperature range
от +5 до +35 C
service life, hour
50 000 h
code
1813001960
energy efficiency class
A
illuminating
color rendition index (CRI)
>80
light flow
3400 lm
flickering factor
<5%
beam angle
D120
color temperature
4000
light source type
LED
emission color
Белый
energy efficiency
85 lm/W
model files
model files
сертификаты
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/2011492.3 kB
Declaration of Conformity EAEU TR 037/2016494.3 kB
Fire Safety Certificate2.5 mB
