MOONWALK LED (120х120) 3W RED WH
_3w_red_wh.jpg&w=1920&q=100)
_3w_red_wh.jpg&w=1024&q=75)
MOONWALK LED (120х120) 3W RED WH
3 Wluminaire power
150 lmlight flow
50 lm/Wenergy efficiency
code1866000100
beam angleD120
weight1.1 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
50 lm/Wlight flow
150 lmflickering factor
<1%beam angle
D120light source type
LEDemission color
Красныйilluminating
energy efficiency
50 lm/W
light flow
150 lm
flickering factor
<1%
beam angle
D120
light source type
LED
emission color
Красный
electrical
luminaire power
3 W
electric shock protection
I
supply voltage
24 V
power factor
> 0,80
constructional
climatic performance
УХЛ1
width
120 mm
height
55 mm
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
length
120 mm
material
Материал полимерный матовый
ingress protection (IP)
IP67
shock resistance (IK)
IK10/20 Дж
weight
1.1 kg
common
code
1866000100
warranty
36 month
energy efficiency class
A
temperature range
от -30 до +35 C
ETIM class
Светильник грунтовый
model files
model files
photometric files
сертификаты
photometric files
ies107 kB
jpg96.2 kB
ldt95.8 kB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/2011677.5 kB
Declaration of Conformity EAEU TR 037/2016287.3 kB
