MGN FLAT.OPL/T 24W OPL 940 BK

MGN FLAT.OPL/T 24W OPL 940 BK
add to favorites
24 Wluminaire power
1850 lmlight flow
77 lm/Wenergy efficiency
code1900000130
color temperature4000
beam angleD120
number of lamps1
performance factor100
  1. main page
  2. catalog
  3. by product type
  4. interior lighting
  5. accent lights and track systems
  6. magnetic busbar system 48 V
  7. MGN FLAT.OPL/T
  8. MGN FLAT.OPL/T 24W OPL 940 BK
options
свернуть все
electricalcommonilluminatingconstructional
rated supply voltage, direct current
48 V
supply voltage, direct current
48 V
luminaire power
24 W
electric shock protection
III
power factor
> 0,95
supply voltage
48 V
electrical
rated supply voltage, direct current
48 V
supply voltage, direct current
48 V
luminaire power
24 W
electric shock protection
III
power factor
> 0,95
supply voltage
48 V
common
ETIM class
Прожектор / Светильник направленного света
warranty
36 month
temperature range
от +5 до +35 C
energy efficiency class
A
code
1900000130
illuminating
color rendition index (CRI)
>90
light flow
1850 lm
flickering factor
<5%
energy efficiency
77 lm/W
beam angle
D120
color temperature
4000
light source type
LED
emission color
Белый
constructional
ingress protection (IP)
IP20
climatic performance
УХЛ4*
material
Металл, пластик
weight
0.273 kg
length, mm
600 mm
width, mm
22 mm
height, mm
43 mm
housing color
Черный
installation width, mm
16 mm
shock resistance (IK)
IK02/0,2 Дж
lamp socket
LED
number of lamps
1
ballast
Без драйвера
