MAGISTRAL LED 200W DS 740 RAL9006
MAGISTRAL LED 200W DS 740 RAL9006
200 Wluminaire power
27800 lmlight flow
139 lm/Wenergy efficiency
code1680000370
beam angleD120
color temperature4000 K
weight16 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
139 lm/Wcolor rendition index (CRI)
>70light flow
27800 lmflickering factor
<5%beam angle
D120color temperature
4000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
139 lm/W
color rendition index (CRI)
>70
light flow
27800 lm
flickering factor
<5%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
luminaire power
200 W
electric shock protection
I
supply voltage
230 V
maximum cross-section of the connected cable
2.5 mm2
power factor
> 0,98
constructional
climatic performance
УХЛ1*
fire safety class
П-ІІІ
width
410 mm
height
188 mm
housing color
Металлик
lamp socket
LED
number of lamps
1
ballast
Драйвер
length
956 mm
material
Алюминий
installation diameter
48-60 mm
ingress protection (IP)
IP66
shock resistance (IK)
5 Дж
weight
16 kg
common
code
1680000370
warranty
60 month
energy efficiency class
A++
temperature range
от -40 до +50 C
service life
50 000 h
ETIM class
Светильник для освещения улиц и площадей
model files
model files
CAD/BIM files
photometric files
сертификаты
CAD/BIM files
model 3dMax2.2 mB
photometric files
ies263.2 kB
jpg123.3 kB
ldt156.3 kB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20112 mB
Declaration of Conformity EAEU TR 037/2016616.5 kB
