LZ.OPL ECO LED 600 5000K

LZ.OPL ECO LED 600 5000K
add to favorites
25 Wluminaire power
2800 lmlight flow
112 lm/Wenergy efficiency
code1074000500
color temperature5000
beam angleD120
weight2.4 kg
  1. main page
  2. catalog
  3. by product type
  4. industrial lighting
  5. up to 5 meters
  6. LZ.OPL ECO LED
  7. LZ.OPL ECO LED 600 5000K
options
свернуть все
electricalilluminatingconstructionalcommon
supply voltage, alternating current
176-264 V
supply voltage, direct current
176-264 V
electric shock protection
II
starting current
25 A
starting current pulse time, µs
250 mks
luminaire power
25 W
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
maximum cross-section of the connected cable, sq. mm
2.5
power factor
> 0,93
supply voltage
230 V
electrical
supply voltage, alternating current
176-264 V
supply voltage, direct current
176-264 V
electric shock protection
II
starting current
25 A
starting current pulse time, µs
250 mks
luminaire power
25 W
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
maximum cross-section of the connected cable, sq. mm
2.5
power factor
> 0,93
supply voltage
230 V
illuminating
color rendition index (CRI)
>80
light flow
2800 lm
flickering factor
<1%
energy efficiency
112 lm/W
beam angle
D120
color temperature
5000
light source type
LED
emission color
Белый
constructional
ingress protection (IP)
IP65
material
Поликарбонат
housing color
Серый
length, mm
660 mm
width, mm
173 mm
height, mm
103 mm
weight
2.4 kg
fire safety class
П-ІІ
climatic performance
УХЛ2*
shock resistance (IK)
IK08/5 Дж
lamp socket
LED
number of lamps
1
ballast
Драйвер
installation length, mm
360 mm
common
ETIM class
Настенно-потолочный светильник
warranty
60 month
temperature range
от -40 до +40 C
energy efficiency class
A+
service life, hour
50 000 h
code
1074000500
model files
model files
CAD/BIM files
CAD model 3DS405.7 kB
model 3dMax968 kB
photometric files
ies107 kB
jpg107.8 kB
ldt85.7 kB
csv412 B
documents
passport2.1 mB
сертификаты
Russian origin550.5 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
CAD/BIM files
CAD model 3DS405.7 kB
model 3dMax968 kB
photometric files
ies107 kB
jpg107.8 kB
ldt85.7 kB
csv412 B
documents
passport2.1 mB
сертификаты
Russian origin550.5 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
