LINER/R DR LED 600 TH B 4000K
LINER/R DR LED 600 TH B 4000K
16 Wluminaire power
1400 lmlight flow
88 lm/Wenergy efficiency
code1474001080
color temperature4000 K
beam angleD120
performance factor100
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
88 lm/Wcolor rendition index (CRI)
>80light flow
1400 lmflickering factor
<1%beam angle
D120color temperature
4000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
88 lm/W
color rendition index (CRI)
>80
light flow
1400 lm
flickering factor
<1%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
starting current pulse time
250 µs
power factor
> 0,95
luminaire power
16 W
electric shock protection
I
supply voltage
230 V
maximum cross-section of the connected cable
1.5 mm2
rated supply voltage, alternating current
230 V
rated supply voltage
230 V
starting current
25 A
constructional
length
562 mm
width
85 mm
height
110 mm
installation length
564 mm
installation width
62 mm
weight
1.6 kg
ingress protection (IP)
IP40
shock resistance (IK)
IK02/0,2 Дж
climatic performance
УХЛ4*
material
Алюминий
housing color
Черный
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
temperature range
от +5 до +35 C
service life
50 000 h
ETIM class
Настенно-потолочный светильник
warranty
60 month
energy efficiency class
A
code
1474001080
model files
model files
CAD/BIM files
photometric files
documents
сертификаты
CAD/BIM files
model 3dMax16.1 mB
photometric files
ies134.1 kB
jpg117.2 kB
ldt83.6 kB
csv423 B
documents
passport3.2 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20112.4 mB
Declaration of Conformity EAEU TR 037/2016541.4 kB
Fire Safety Certificate1.7 mB
