LINER 60/R (1500) 30W OPL 940 WH
LINER 60/R (1500) 30W OPL 940 WH
30 Wluminaire power
3200 lmlight flow
107 lm/Wenergy efficiency
code1474004620
color temperature4000 K
beam angleD120
old nameLINER 60/R (1500) 940 WH
performance factor100
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
107 lm/Wcolor rendition index (CRI)
>90light flow
3200 lmbeam angle
D120color temperature
4000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
107 lm/W
color rendition index (CRI)
>90
light flow
3200 lm
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
electric shock protection
I
luminaire power
30 W
supply voltage
230 V
power factor
> 0,95
maximum cross-section of the connected cable
1.5 mm2
constructional
length
1538 mm
width
85 mm
height
84 mm
installation length
1520 mm
installation width
65 mm
weight
4.8 kg
ingress protection (IP)
IP40
shock resistance (IK)
IK02/0,2 Дж
climatic performance
УХЛ4*
fire safety class
П-ІІІ
material
Алюминий
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
warranty
60 month
temperature range
от +5 до +35 C
service life
50 000 h
energy efficiency class
A+
ETIM class
Настенно-потолочный светильник
code
1474004620
model files
model files
photometric files
сертификаты
photometric files
ies107 kB
jpg76.3 kB
ldt68.7 kB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/2011511 kB
Declaration of Conformity EAEU TR 037/2016508.6 kB
Fire Safety Certificate1.7 mB
