LED MALL ECO 35 S IP65 4000K (ППГнг(А)-FRHF 3х1,5, 1м, вывод с торца)
archive
archive
LED MALL ECO 35 S IP65 4000K (ППГнг(А)-FRHF 3х1,5, 1м, вывод с торца)
40 Wluminaire power
4100 lmlight flow
103 lm/Wenergy efficiency
code1598002370
color temperature4000
beam angleD100
number of lamps1
performance factor100
options
свернуть все
electricalconstructionalcommonilluminating
starting current
25 Astarting current pulse time, µs
250 mksrated supply voltage, alternating current
230 Vrated supply voltage, direct current
230 Vsupply voltage, alternating current
176-264 Vsupply voltage, direct current
176-264 Vluminaire power
40 Welectric shock protection
Ipower factor
> 0,95supply voltage
230 Velectrical
starting current
25 A
starting current pulse time, µs
250 mks
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
supply voltage, alternating current
176-264 V
supply voltage, direct current
176-264 V
luminaire power
40 W
electric shock protection
I
power factor
> 0,95
supply voltage
230 V
constructional
maximum cross-section of the connected cable, sq. mm
1.5
ingress protection (IP)
IP65
climatic performance
УХЛ4*
material
Алюминий
weight
3 kg
length, mm
1500 mm
width, mm
53 mm
height, mm
100 mm
housing color
Металлик
installation length, mm
1300 mm
shock resistance (IK)
IK02/0,2 Дж
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
ETIM class
Светильник (электрический блок) для магистральных систем световых линий
warranty
36 month
temperature range
от -25 до +40 C
energy efficiency class
A+
service life, hour
50 000 h
code
1598002370
illuminating
color rendition index (CRI)
>80
light flow
4100 lm
flickering factor
<5%
energy efficiency
103 lm/W
beam angle
D100
color temperature
4000
light source type
LED
emission color
Белый
model files
model files
documents
сертификаты
documents
passport697.1 kB
сертификаты
Voluntary certificate2.7 mB
Certificate of conformity TRTS 020/2011, TRTS 004/20111.6 mB
Declaration of Conformity EAEU TR 037/2016595.1 kB
Fire Safety Certificate2.5 mB
