зарегистрирована в реестре российской промышленной продукции
LEADER LED 140W A30 750 RAL9006 DALI
зарегистрирована в реестре российской промышленной продукции
LEADER LED 140W A30 750 RAL9006 DALI
142 Wluminaire power
20800 lmlight flow
146 lm/Wenergy efficiency
code
1350002430
number from the register of Russian industrial products
10770476
beam angle
A30
color temperature
5000 K
weight
11.1 kg
- main page
- catalog
- by product type
- outdoor lighting
- spotlights
- universal
- LEADER LED
- LEADER LED 140W A30 750 RAL9006 DALI
options
свернуть все
illuminatingelectricalconstructionalemergencyLMS optionscommonpackage
energy efficiency
146 lm/Wcolor rendition index (CRI)
>70light flow
20800 lmflickering factor
<5%beam angle
A30color temperature
5000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
146 lm/W
color rendition index (CRI)
>70
light flow
20800 lm
flickering factor
<5%
beam angle
A30
color temperature
5000 K
light source type
LED
emission color
Белый
electrical
luminaire power
142 W
electric shock protection
I
supply voltage
230 V
maximum cross-section of the connected cable
2.5 mm2
power factor
> 0,98
constructional
fire safety class
П-I,II,IIa,ІІІ
length
420 mm
height
80 mm
installation length
200 mm
housing color
Металлик
lamp socket
LED
number of lamps
1
ballast
Драйвер DALI
width
480 mm
mounting type
material
Алюминий
climatic performance
УХЛ1*
ingress protection (IP)
IP66
shock resistance (IK)
IK08/5 Дж
weight
11.1 kg
emergency
emergency power supply
Нет
LMS options
dimming
DALI
common
code
1350002430
warranty
60 month
energy efficiency class
A++
temperature range
от -40 до +40 C
service life
50 000 h
ETIM class
Прожектор / Светильник направленного света
package
Package contents
Светильник - 1 шт.
Паспорт - 1 шт.
Упаковка - 1 шт.
model files
model files
photometric files
сертификаты
photometric files
ies107.1 kB
jpg78.1 kB
ldt71.2 kB
csv451 B
сертификаты
Russian origin329.9 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20111.4 mB
Declaration of Conformity EAEU TR 037/2016555.9 kB
