INSEL LB/S LED G3 260W D60 850 WH SB
INSEL LB/S LED G3 260W D60 850 WH SB
275 Wluminaire power
38600 lmlight flow
140 lm/Wenergy efficiency
code1334002850
color temperature5000
beam angleD60
weight7.4 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>80light flow
38600 lmflickering factor
<2%energy efficiency
140 lm/Wbeam angle
D60color temperature
5000light source type
LEDemission color
Белыйilluminating
color rendition index (CRI)
>80
light flow
38600 lm
flickering factor
<2%
energy efficiency
140 lm/W
beam angle
D60
color temperature
5000
light source type
LED
emission color
Белый
electrical
power factor
> 0,96
luminaire power
275 W
electric shock protection
I
maximum cross-section of the connected cable, sq. mm
2.5
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
starting current
116 A
supply voltage
230 V
starting current pulse time, µs
400 mks
constructional
shock resistance (IK)
IK08/5 Дж
climatic performance
УХЛ1*
fire safety class
П-I,II,IIa,ІІІ
material
Алюминий
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
ingress protection (IP)
IP66/IP67
weight
7.4 kg
length, mm
331 mm
width, mm
331 mm
height, mm
169 mm
installation length, mm
200 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A++
service life, hour
50 000 h
temperature range
от -40 до +40 C
code
1334002850
model files
model files
photometric files
documents
сертификаты
photometric files
ies263.2 kB
jpg88.1 kB
ldt168.9 kB
csv407 B
documents
passport4 mB
сертификаты
Russian origin279.6 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
