INSEL LB/S LED G3 260W D130 850 WH SB
INSEL LB/S LED G3 260W D130 850 WH SB
270 Wluminaire power
40200 lmlight flow
149 lm/Wenergy efficiency
code1334002880
color temperature5000 K
beam angleD130
weight7 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>80light flow
40200 lmflickering factor
<5%energy efficiency
149 lm/Wbeam angle
D130color temperature
5000 Klight source type
LEDemission color
Белыйilluminating
color rendition index (CRI)
>80
light flow
40200 lm
flickering factor
<5%
energy efficiency
149 lm/W
beam angle
D130
color temperature
5000 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,96
luminaire power
270 W
electric shock protection
I
maximum cross-section of the connected cable
2.5 mm2
supply voltage
230 V
constructional
shock resistance (IK)
IK08/5 Дж
climatic performance
УХЛ1*
fire safety class
П-I,II,IIa,ІІІ
material
Алюминий
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
ingress protection (IP)
IP66/IP67
weight
7 kg
length
331 mm
width
331 mm
height
169 mm
installation length
200 mm
installation width
360 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A++
service life
50 000 h
temperature range
от -40 до +40 C
code
1334002880
model files
model files
photometric files
сертификаты
photometric files
ies107.1 kB
jpg77.8 kB
ldt65.7 kB
csv440 B
сертификаты
Russian origin279.6 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
