INSEL LB/S LED G3 230W D130 850 WH SB
INSEL LB/S LED G3 230W D130 850 WH SB
240 Wluminaire power
36400 lmlight flow
152 lm/Wenergy efficiency
code1334003020
color temperature5000
beam angleD130
weight7 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>80light flow
36400 lmflickering factor
<5%energy efficiency
152 lm/Wbeam angle
D130color temperature
5000light source type
LEDemission color
Белыйilluminating
color rendition index (CRI)
>80
light flow
36400 lm
flickering factor
<5%
energy efficiency
152 lm/W
beam angle
D130
color temperature
5000
light source type
LED
emission color
Белый
electrical
power factor
> 0,96
luminaire power
240 W
electric shock protection
I
maximum cross-section of the connected cable, sq. mm
2.5
supply voltage
230 V
constructional
shock resistance (IK)
IK08/5 Дж
climatic performance
УХЛ1*
fire safety class
П-I,II,IIa,ІІІ
material
Алюминий
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
ingress protection (IP)
IP66/IP67
weight
7 kg
length, mm
331 mm
width, mm
331 mm
height, mm
169 mm
installation length, mm
200 mm
installation width, mm
360 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A++
service life, hour
50 000 h
temperature range
от -40 до +40 C
code
1334003020
model files
model files
photometric files
сертификаты
photometric files
ies107.1 kB
jpg77.8 kB
ldt65.7 kB
csv430 B
сертификаты
Russian origin279.6 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
