INSEL LB/R LED G3 70W D60 850 WH
INSEL LB/R LED G3 70W D60 850 WH
76 Wluminaire power
11600 lmlight flow
153 lm/Wenergy efficiency
code1332002630
color temperature5000 K
beam angleD60
weight8.4 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>80light flow
11600 lmflickering factor
<1%energy efficiency
153 lm/Wbeam angle
D60color temperature
5000 Klight source type
LEDemission color
Белыйilluminating
color rendition index (CRI)
>80
light flow
11600 lm
flickering factor
<1%
energy efficiency
153 lm/W
beam angle
D60
color temperature
5000 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,96
luminaire power
76 W
electric shock protection
I
maximum cross-section of the connected cable
2.5 mm2
rated supply voltage, alternating current
230 V
starting current
75 A
supply voltage
230 V
starting current pulse time
200 µs
constructional
shock resistance (IK)
IK08/5 Дж
climatic performance
УХЛ1*
fire safety class
П-I,II,IIa,ІІІ
material
Алюминий
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
ingress protection (IP)
IP66
weight
8.4 kg
length
390 mm
width
390 mm
height
112 mm
installation length
360 mm
installation width
360 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A++
service life
50 000 h
temperature range
от -40 до +60 C
code
1332002630
model files
model files
photometric files
documents
сертификаты
photometric files
ies263.2 kB
jpg88.1 kB
ldt168.9 kB
csv403 B
documents
passport1.7 mB
сертификаты
Russian origin279.6 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20112.4 mB
Declaration of Conformity EAEU TR 037/2016541.4 kB
Fire Safety Certificate1.7 mB
