HB LED 150 D90 5000K G3
HB LED 150 D90 5000K G3
138 Wluminaire power
22600 lmlight flow
164 lm/Wenergy efficiency
code1224006900
color temperature5000
beam angleD90
weight3.61 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>80light flow
22600 lmflickering factor
<1%energy efficiency
164 lm/Wbeam angle
D90color temperature
5000light source type
LEDemission color
Белыйilluminating
color rendition index (CRI)
>80
light flow
22600 lm
flickering factor
<1%
energy efficiency
164 lm/W
beam angle
D90
color temperature
5000
light source type
LED
emission color
Белый
electrical
power factor
> 0,96
luminaire power
138 W
electric shock protection
I
maximum cross-section of the connected cable, sq. mm
2.5
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
starting current
50 A
supply voltage
230 V
starting current pulse time, µs
500 mks
constructional
shock resistance (IK)
IK05/0,7 Дж
climatic performance
УХЛ1*
material
Алюминий
housing color
Металлик
lamp socket
LED
number of lamps
1
ballast
Драйвер
ingress protection (IP)
IP66
weight
3.61 kg
length, mm
480 mm
width, mm
237 mm
height, mm
124 mm
installation length, mm
180 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A++
service life, hour
50 000 h
temperature range
от -40 до +55 C
code
1224006900
model files
model files
photometric files
documents
сертификаты
photometric files
ies107 kB
jpg78.5 kB
ldt64.8 kB
documents
passport2.4 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
