HB LED 800 D60 5000K G2
HB LED 800 D60 5000K G2
830 Wluminaire power
107600 lmlight flow
130 lm/Wenergy efficiency
code1224005870
color temperature5000 K
beam angleD60
weight26 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>80light flow
107600 lmflickering factor
<1%energy efficiency
130 lm/Wbeam angle
D60color temperature
5000 Klight source type
LEDemission color
Белыйilluminating
color rendition index (CRI)
>80
light flow
107600 lm
flickering factor
<1%
energy efficiency
130 lm/W
beam angle
D60
color temperature
5000 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,97
luminaire power
830 W
electric shock protection
I
maximum cross-section of the connected cable
2.5 mm2
rated supply voltage, alternating current
230 V
rated supply voltage
230 V
starting current
6 A
supply voltage
230 V
starting current pulse time
11800 µs
constructional
shock resistance (IK)
IK07/2 Дж
climatic performance
УХЛ1*
fire safety class
П-ІІ
material
Алюминий
housing color
Металлик
lamp socket
LED
number of lamps
1
ballast
Драйвер
ingress protection (IP)
IP66
weight
26 kg
length
710 mm
width
532 mm
height
417 mm
installation length
340 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A+
service life
50 000 h
temperature range
от -40 до +40 C
code
1224005870
model files
model files
photometric files
documents
сертификаты
photometric files
jpg85.5 kB
ldt61.2 kB
documents
passport5.1 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20111.6 mB
Declaration of Conformity EAEU TR 037/2016595.1 kB
Fire Safety Certificate2.5 mB
