HB LED 30 D80 5000K (EXTREME)

model is discontinued
model is discontinued
HB LED 30 D80 5000K (EXTREME)
add to favorites
30 Wluminaire power
28800 lmlight flow
960 lm/Wenergy efficiency
code1224006080
color temperature5000 K
beam angleA30
weight3.7 kg
  1. main page
  2. catalog
  3. by product type
  4. industrial lighting
  5. over 12 meters
  6. свыше 12 метров
  7. HB LED EXTREME
  8. HB LED 30 D80 5000K (EXTREME)
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>75
light flow
28800 lm
flickering factor
<1%
energy efficiency
960 lm/W
beam angle
A30
color temperature
5000 K
light source type
LED
emission color
Белый
illuminating
color rendition index (CRI)
>75
light flow
28800 lm
flickering factor
<1%
energy efficiency
960 lm/W
beam angle
A30
color temperature
5000 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,96
luminaire power
30 W
electric shock protection
I
maximum cross-section of the connected cable
2.5 mm2
supply voltage
230 V
constructional
climatic performance
УХЛ1
material
Алюминий
housing color
Металлик
lamp socket
LED
number of lamps
1
ballast
Драйвер
shock resistance (IK)
IK07/2 Дж
weight
3.7 kg
ingress protection (IP)
IP65
length
463 mm
width
110 mm
height
160 mm
installation length
180 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A++
service life
50 000 h
temperature range
от -40 до +55 C
code
1224006080
model files
model files
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20111.6 mB
Declaration of Conformity EAEU TR 037/2016595.1 kB
Fire Safety Certificate2.5 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20111.6 mB
Declaration of Conformity EAEU TR 037/2016595.1 kB
Fire Safety Certificate2.5 mB
