EVOLINE FLEX GRAZE (1000) 18W D15 830 WH with connector Direct Double
EVOLINE FLEX GRAZE (1000) 18W D15 830 WH with connector Direct Double
19 Wluminaire power
1300 lmlight flow
68 lm/Wenergy efficiency
code
1006006090
beam angle
D15
color temperature
3000 K
weight
7.32 kg
- main page
- catalog
- by product type
- outdoor lighting
- decorative
- EVOLINE FLEX WALL GRAZER
- EVOLINE FLEX GRAZE (1000) 18W D15 830 WH with connector Direct Double
options
свернуть все
illuminatingelectricalconstructionalemergencycommonpackage
energy efficiency
68 lm/Wcolor rendition index (CRI)
>80light flow
1300 lmbeam angle
D15color temperature
3000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
68 lm/W
color rendition index (CRI)
>80
light flow
1300 lm
beam angle
D15
color temperature
3000 K
light source type
LED
emission color
Белый
electrical
luminaire power
19 W
electric shock protection
III
supply voltage
24 V
maximum cross-section of the connected cable
2.5 mm2
supply voltage, direct current
24 V
constructional
length
1000 mm
height
18 mm
installation length
180 mm
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Без драйвера
width
18 mm
mounting type
material
Силикон
climatic performance
УХЛ1*
ingress protection (IP)
IP68
shock resistance (IK)
IK07/2 Дж
weight
7.32 kg
emergency
emergency power supply
Нет
common
code
1006006090
warranty
36 month
energy efficiency class
A
temperature range
от -25 до +40 C
service life
50 000 h
ETIM class
Световая полоса/ лента/ шнур
package
Package contents
Светильник - 1 шт.
Паспорт - 1 шт.
Упаковка - 1 шт.
model files
model files
photometric files
documents
сертификаты
photometric files
ies45.9 kB
jpg188.3 kB
ldt31.9 kB
csv499 B
documents
passport1.2 mB
сертификаты
Declaration of Conformity TRTS 020/2011620.9 kB
Declaration of Conformity EAEU TR 037/2016519.6 kB
