DL POWER LED 40 D80 HFD 4000K

DL POWER LED 40 D80 HFD 4000K
add to favorites
36 Wluminaire power
3500 lmlight flow
97 lm/Wenergy efficiency
code1170001460
color temperature4000
beam angleD80
number of lamps1
performance factor100
  1. main page
  2. catalog
  3. by product type
  4. interior lighting
  5. downlights
  6. DL POWER LED
  7. DL POWER LED 40 D80 HFD 4000K
options
свернуть все
electricalconstructionalcommonilluminatingLMS options
starting current
10 A
starting current pulse time, µs
200 mks
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
supply voltage, alternating current
100-264 V
supply voltage, direct current
176-264 V
luminaire power
36 W
electric shock protection
II
power factor
> 0,90
supply voltage
230 V
electrical
starting current
10 A
starting current pulse time, µs
200 mks
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
supply voltage, alternating current
100-264 V
supply voltage, direct current
176-264 V
luminaire power
36 W
electric shock protection
II
power factor
> 0,90
supply voltage
230 V
constructional
maximum cross-section of the connected cable, sq. mm
2.5
ingress protection (IP)
IP20
climatic performance
УХЛ4*
material
Алюминий
weight
2.9 kg
diameter, mm
234 mm
height, mm
127 mm
housing color
Белый
installation diameter, mm
210 mm
shock resistance (IK)
IK02/0,2 Дж
lamp socket
LED
number of lamps
1
ballast
Драйвер DALI
common
ETIM class
Прожектор / Светильник направленного света
warranty
36 month
temperature range
от +5 до +35 C
energy efficiency class
A+
service life, hour
50 000 h
code
1170001460
illuminating
color rendition index (CRI)
>80
light flow
3500 lm
flickering factor
<1%
energy efficiency
97 lm/W
beam angle
D80
color temperature
4000
light source type
LED
emission color
Белый
LMS options
dimming
DALI
model files
model files
CAD/BIM files
CAD model 3DS145.8 kB
model 3dMax632 kB
photometric files
ies263.2 kB
jpg66.6 kB
ldt153.1 kB
documents
passport1.8 mB
сертификаты
Voluntary certificate2.7 mB
Certificate of conformity TRTS 020/2011, TRTS 004/20112.4 mB
Declaration of Conformity EAEU TR 037/2016541.4 kB
Fire Safety Certificate1.7 mB
CAD/BIM files
CAD model 3DS145.8 kB
model 3dMax632 kB
photometric files
ies263.2 kB
jpg66.6 kB
ldt153.1 kB
documents
passport1.8 mB
сертификаты
Voluntary certificate2.7 mB
Certificate of conformity TRTS 020/2011, TRTS 004/20112.4 mB
Declaration of Conformity EAEU TR 037/2016541.4 kB
Fire Safety Certificate1.7 mB
