DL POWER LED 40 D80 EM 4000K
DL POWER LED 40 D80 EM 4000K
36 Wluminaire power
3500 lmlight flow
97 lm/Wenergy efficiency
code1170001760
color temperature4000
beam angleD80
number of lamps1
performance factor100
options
свернуть все
electricalconstructionalcommonilluminatingemergency
starting current
60 Astarting current pulse time, µs
400 mksrated supply voltage, alternating current
230 Vsupply voltage, alternating current
198-264 Vluminaire power
36 Welectric shock protection
Ipower factor
> 0,90supply voltage
230 Velectrical
starting current
60 A
starting current pulse time, µs
400 mks
rated supply voltage, alternating current
230 V
supply voltage, alternating current
198-264 V
luminaire power
36 W
electric shock protection
I
power factor
> 0,90
supply voltage
230 V
constructional
maximum cross-section of the connected cable, sq. mm
2.5
ingress protection (IP)
IP20
climatic performance
УХЛ4*
material
Алюминий
weight
3.4 kg
diameter, mm
234 mm
height, mm
127 mm
housing color
Белый
installation diameter, mm
210 mm
shock resistance (IK)
IK02/0,2 Дж
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
ETIM class
Прожектор / Светильник направленного света
warranty
36 month
temperature range
от +5 до +35 C
energy efficiency class
A+
service life, hour
50 000 h
code
1170001760
illuminating
color rendition index (CRI)
>80
light flow
3500 lm
flickering factor
<1%
energy efficiency
97 lm/W
beam angle
D80
color temperature
4000
light source type
LED
emission color
Белый
emergency
operating time in emergency mode, hours
1 h
luminous flux in emergency mode
14% lm
model files
model files
CAD/BIM files
photometric files
documents
сертификаты
CAD/BIM files
CAD model 3DS145.8 kB
model 3dMax632 kB
photometric files
ies263.2 kB
jpg69.2 kB
ldt153.1 kB
documents
passport1.8 mB
сертификаты
Voluntary certificate2.7 mB
Certificate of conformity TRTS 020/2011, TRTS 004/20112.4 mB
Declaration of Conformity EAEU TR 037/2016541.4 kB
Fire Safety Certificate1.7 mB
