CYCLE/P (4000) 840 WH
CYCLE/P (4000) 840 WH
200 Wluminaire power
16400 lmlight flow
82 lm/Wenergy efficiency
code
1101505280
color temperature
4000 K
beam angle
D120
performance factor
100
options
свернуть все
illuminatingelectricalconstructionalemergencycommonpackage
energy efficiency
82 lm/Wcolor rendition index (CRI)
>80light flow
16400 lmflickering factor
<1%beam angle
D120color temperature
4000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
82 lm/W
color rendition index (CRI)
>80
light flow
16400 lm
flickering factor
<1%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,90
luminaire power
200 W
electric shock protection
I
supply voltage
230 V
maximum cross-section of the connected cable
2.5 mm2
constructional
diameter
4000 mm
height
70 mm
weight
29.9 kg
ingress protection (IP)
IP40
shock resistance (IK)
IK01/0,15 Дж
climatic performance
УХЛ4*
fire safety class
П-ІІІ
material
Алюминий
housing color
Белый
mounting type
lamp socket
LED
number of lamps
1
ballast
Драйвер
Type roof
emergency
emergency power supply
Нет
common
temperature range
от +5 до +35 C
service life
50 000 h
ETIM class
Светильник подвесной
warranty
36 month
energy efficiency class
A
code
1101505280
package
Package contents
Светильник - 1 шт.
Паспорт - 1 шт.
Упаковка - 1 шт.
Комплект монтажный - 1 шт.
model files
model files
photometric files
сертификаты
photometric files
ies263.2 kB
jpg75.4 kB
ldt165.8 kB
csv425 B
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/2011293.4 kB
Declaration of Conformity EAEU TR 037/2016292.4 kB
