CHAMPION 1800W D30 950 BK FB
CHAMPION 1800W D30 950 BK FB
1800 Wluminaire power
198000 lmlight flow
110 lm/Wenergy efficiency
code1879000590
beam angleD30
color temperature5000
weight29 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
110 lm/Wcolor rendition index (CRI)
>90light flow
198000 lmflickering factor
<1%beam angle
D30color temperature
5000light source type
LEDemission color
Белыйilluminating
energy efficiency
110 lm/W
color rendition index (CRI)
>90
light flow
198000 lm
flickering factor
<1%
beam angle
D30
color temperature
5000
light source type
LED
emission color
Белый
electrical
luminaire power
1800 W
electric shock protection
I
starting current pulse time, µs
1200 mks
rated supply voltage, alternating current
230 V
supply voltage
230 V
starting current
70 A
maximum cross-section of the connected cable, sq. mm
2.5
supply voltage, direct current
127-431 V
supply voltage, alternating current
90-305 V
power factor
> 0,97
constructional
climatic performance
УХЛ1*
fire safety class
П-I,II,ІІІ
width, mm
680 mm
height, mm
320 mm
installation length, mm
392 mm
housing color
Черный
lamp socket
LED
number of lamps
1
ballast
Драйвер
length, mm
760 mm
material
Алюминий
ingress protection (IP)
IP66
shock resistance (IK)
IK07/2 Дж
weight
29 kg
common
code
1879000590
warranty
60 month
energy efficiency class
A+
temperature range
от -40 до +45 C
service life, hour
50 000 h
ETIM class
Светильник для освещения высоких пролетов (хайбей)
