CD LED 27 4000K CRI90
CD LED 27 4000K CRI90
22 Wluminaire power
2200 lmlight flow
100 lm/Wenergy efficiency
code1134000440
color temperature4000
beam angleD120
performance factor100
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
100 lm/Wcolor rendition index (CRI)
>90light flow
2200 lmflickering factor
<5%beam angle
D120color temperature
4000light source type
LEDemission color
Белыйilluminating
energy efficiency
100 lm/W
color rendition index (CRI)
>90
light flow
2200 lm
flickering factor
<5%
beam angle
D120
color temperature
4000
light source type
LED
emission color
Белый
electrical
starting current pulse time, µs
400 mks
electric shock protection
II
luminaire power
22 W
supply voltage
230 V
power factor
> 0,95
maximum cross-section of the connected cable, sq. mm
1.5
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
starting current
15 A
constructional
diameter, mm
390 mm
height, mm
144 mm
installation diameter, mm
255 mm
weight
2.3 kg
ingress protection (IP)
IP65
shock resistance (IK)
IK02/0,2 Дж
climatic performance
УХЛ2*
material
Поликарбонат
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
warranty
36 month
temperature range
от -20 до +40 C
service life, hour
50 000 h
energy efficiency class
A+
ETIM class
Настенно-потолочный светильник
code
1134000440
model files
model files
photometric files
documents
сертификаты
photometric files
ies134.1 kB
jpg161.7 kB
ldt109.5 kB
csv409 B
documents
passport1.7 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
