Кнопка взрывозащищенная B1-01-3-Exd
Кнопка взрывозащищенная B1-01-3-Exd
IP66 ingress protection (IP)
от -60 до +60 Ctemperature range
code2327029180
gas markingEx d IIB+H2 Gb U
materialПолиамид
weight0.09 kg
options
свернуть все
electricalconstructionalcommonexplosion-proof
rated supply voltage, alternating current
230 Vsupply voltage, alternating current
12-250 Vsupply voltage, direct current
12-60 Velectric shock protection
Ielectrical
rated supply voltage, alternating current
230 V
supply voltage, alternating current
12-250 V
supply voltage, direct current
12-60 V
electric shock protection
I
constructional
ingress protection (IP)
IP66
material
Полиамид
weight
0.09 kg
length, mm
70 mm
width, mm
37 mm
height, mm
85 mm
housing color
Серый
climatic performance
УХЛ1
maximum cross-section of the connected cable, sq. mm
2.5
shock resistance (IK)
IK08/7 Дж
common
ETIM class
Нажимная кнопка (кнопочный выключатель/переключатель) в сборе
warranty
36 month
temperature range
от -60 до +60 C
code
2327029180
explosion-proof
gas marking
Ex d IIB+H2 Gb U
dust marking
Ex tb IIIC Db U
gas explosion-proof (type)
Ex d
gas explosion-proof (groups of equipment)
IIB+H2
model files
model files
сертификаты
сертификаты
Certificate of conformity TRTS 012/2011464.4 kB
Declaration of Conformity EAEU TR 037/2016278.1 kB
