ATHLET 230W D30 750 WH SBL
ATHLET 230W D30 750 WH SBL
250 Wluminaire power
36200 lmlight flow
145 lm/Wenergy efficiency
code1875000530
beam angleD30
color temperature5000
weight8 kg
options
свернуть все
electricalconstructionalcommonilluminating
luminaire power
250 Welectric shock protection
Ipower factor
> 0,96supply voltage
230 Velectrical
luminaire power
250 W
electric shock protection
I
power factor
> 0,96
supply voltage
230 V
constructional
ingress protection (IP)
IP66
fire safety class
П-I,II,IIa,ІІІ
material
Алюминий
weight
8 kg
length, mm
385 mm
width, mm
410 mm
height, mm
215 mm
housing color
Белый
climatic performance
УХЛ1*
maximum cross-section of the connected cable, sq. mm
2.5
shock resistance (IK)
IK07/2 Дж
installation length, mm
220 mm
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
code
1875000530
ETIM class
Прожектор / Светильник направленного света
warranty
60 month
temperature range
от -40 до +60 C
energy efficiency class
A++
service life, hour
50 000 h
illuminating
energy efficiency
145 lm/W
color rendition index (CRI)
>70
light flow
36200 lm
flickering factor
<5%
beam angle
D30
color temperature
5000
light source type
LED
emission color
Белый
model files
model files
photometric files
сертификаты
media
photometric files
ies263.2 kB
jpg84.4 kB
ldt165.6 kB
сертификаты
Russian origin279.6 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20111.2 mB
Declaration of Conformity EAEU TR 037/2016505.1 kB
media
brochure4.9 mB
