ARCTIC STANDARD 1500 TH 4000K
ARCTIC STANDARD 1500 TH 4000K
44 Wluminaire power
4500 lmlight flow
102 lm/Wenergy efficiency
code1088000550
color temperature4000 K
beam angleD120
performance factor100
weight3.2 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
102 lm/Wcolor rendition index (CRI)
>80light flow
4500 lmflickering factor
<3%beam angle
D120color temperature
4000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
102 lm/W
color rendition index (CRI)
>80
light flow
4500 lm
flickering factor
<3%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
starting current pulse time
250 µs
electric shock protection
I
luminaire power
44 W
supply voltage
230 V
power factor
> 0,98
maximum cross-section of the connected cable
2.5 mm2
rated supply voltage, alternating current
230 V
rated supply voltage
230 V
starting current
25 A
constructional
length
1582 mm
width
96 mm
height
110 mm
installation length
1230 mm
weight
3.2 kg
ingress protection (IP)
IP65
shock resistance (IK)
IK08/5 Дж
climatic performance
УХЛ2*
fire safety class
П-ІІ
material
Пластик
housing color
Серый
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
warranty
60 month
temperature range
от -40 до +40 C
service life
50 000 h
energy efficiency class
A+
ETIM class
Настенно-потолочный светильник
code
1088000550
model files
model files
CAD/BIM files
photometric files
documents
сертификаты
CAD/BIM files
model 3dMax2 mB
photometric files
ies134.1 kB
jpg165.9 kB
ldt108.9 kB
csv414 B
documents
passport1.8 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
accessories
Cable mounting kit Arctic /2/0.01kgarticle: 2069000010
