ARCTIC.OPL ECO LED (1200) 50W 840 GY through wiring
ARCTIC.OPL ECO LED (1200) 50W 840 GY through wiring
50 Wluminaire power
6400 lmlight flow
128 lm/Wenergy efficiency
code1088002150
color temperature4000 K
beam angleD120
performance factor100
weight3.3 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
128 lm/Wcolor rendition index (CRI)
>80light flow
6400 lmflickering factor
<1%beam angle
D120color temperature
4000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
128 lm/W
color rendition index (CRI)
>80
light flow
6400 lm
flickering factor
<1%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
starting current pulse time
250 µs
electric shock protection
II
luminaire power
50 W
supply voltage
230 V
power factor
> 0,96
maximum cross-section of the connected cable
2.5 mm2
rated supply voltage, alternating current
230 V
rated supply voltage
230 V
starting current
30 A
constructional
length
1278 mm
width
170 mm
height
110 mm
installation length
932 mm
weight
3.3 kg
ingress protection (IP)
IP65
shock resistance (IK)
IK08/5 Дж
climatic performance
УХЛ2*
fire safety class
П-ІІ
material
Пластик
housing color
Серый
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
warranty
60 month
temperature range
от -40 до +40 C
service life
50 000 h
energy efficiency class
A+
ETIM class
Настенно-потолочный светильник
code
1088002150
