ARCTIC.OPL ECO LED 600 TH 5000K (AGRO)
archive
archive
ARCTIC.OPL ECO LED 600 TH 5000K (AGRO)
20 Wluminaire power
1950 lmlight flow
98 lm/Wenergy efficiency
code1088000660
color temperature5000
beam angleD120
weight1.5 kg
options
свернуть все
electricalconstructionalcommonilluminating
starting current
23 Astarting current pulse time, µs
352 mksrated supply voltage, alternating current
220 Vrated supply voltage, direct current
200-240 Vsupply voltage, alternating current
198-264 Vsupply voltage, direct current
176-280 Vluminaire power
20 Welectric shock protection
IIpower factor
> 0,91supply voltage
230 Velectrical
starting current
23 A
starting current pulse time, µs
352 mks
rated supply voltage, alternating current
220 V
rated supply voltage, direct current
200-240 V
supply voltage, alternating current
198-264 V
supply voltage, direct current
176-280 V
luminaire power
20 W
electric shock protection
II
power factor
> 0,91
supply voltage
230 V
constructional
ingress protection (IP)
IP65
fire safety class
П-ІІ
material
Пластик
weight
1.5 kg
housing color
Белый
climatic performance
УХЛ2
maximum cross-section of the connected cable, sq. mm
2.5
length, mm
671 mm
width, mm
100 mm
height, mm
110 mm
shock resistance (IK)
IK02/0,2 Дж
lamp socket
LED
number of lamps
1
ballast
Драйвер
installation length, mm
445 mm
common
ETIM class
Настенно-потолочный светильник
warranty
36 month
temperature range
от -40 до +40 C
energy efficiency class
A+
service life, hour
50 000 h
code
1088000660
illuminating
light flow
1950 lm
flickering factor
<2%
energy efficiency
98 lm/W
beam angle
D120
color temperature
5000
light source type
LED
emission color
Белый
color rendition index (CRI)
>85
model files
model files
documents
сертификаты
documents
passport378 kB
сертификаты
Voluntary certificate2.7 mB
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016595.1 kB
Fire Safety Certificate2.5 mB
