INSEL LB/S LED G3 70W D30 757 WH SB
INSEL LB/S LED G3 70W D30 757 WH SB
76 Wluminaire power
12000 lmlight flow
158 lm/Wenergy efficiency
code1334003620
color temperature5700 K
beam angleD30
weight7 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>70light flow
12000 lmflickering factor
<1%energy efficiency
158 lm/Wbeam angle
D30color temperature
5700 Klight source type
LEDemission color
Белыйilluminating
color rendition index (CRI)
>70
light flow
12000 lm
flickering factor
<1%
energy efficiency
158 lm/W
beam angle
D30
color temperature
5700 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,96
luminaire power
76 W
electric shock protection
I
maximum cross-section of the connected cable
2.5 mm2
rated supply voltage, alternating current
230 V
rated supply voltage
230 V
starting current
50 A
supply voltage
230 V
starting current pulse time
300 µs
constructional
shock resistance (IK)
IK08/5 Дж
climatic performance
УХЛ1*
fire safety class
П-I,II,IIa,ІІІ
material
Алюминий
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
ingress protection (IP)
IP66
weight
7 kg
length
331 mm
width
331 mm
height
169 mm
installation length
200 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A++
service life
100 000 h
temperature range
от -40 до +60 C
code
1334003620
model files
model files
photometric files
сертификаты
photometric files
ies263.2 kB
jpg84.4 kB
ldt165.6 kB
сертификаты
Russian origin279.6 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
