INSEL LB/R LED G3 70W D90 757 WH
INSEL LB/R LED G3 70W D90 757 WH
76 Wluminaire power
12400 lmlight flow
163 lm/Wenergy efficiency
code1332002570
color temperature5700 K
beam angleD90
weight8.4 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
color rendition index (CRI)
>70light flow
12400 lmflickering factor
<1%energy efficiency
163 lm/Wbeam angle
D90color temperature
5700 Klight source type
LEDemission color
Белыйilluminating
color rendition index (CRI)
>70
light flow
12400 lm
flickering factor
<1%
energy efficiency
163 lm/W
beam angle
D90
color temperature
5700 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,96
luminaire power
76 W
electric shock protection
I
maximum cross-section of the connected cable
2.5 mm2
rated supply voltage, alternating current
230 V
rated supply voltage
230 V
starting current
50 A
supply voltage
230 V
starting current pulse time
300 µs
constructional
shock resistance (IK)
IK08/5 Дж
climatic performance
УХЛ1*
fire safety class
П-I,II,IIa,ІІІ
material
Алюминий
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
ingress protection (IP)
IP66
weight
8.4 kg
length
390 mm
width
390 mm
height
112 mm
installation length
360 mm
installation width
360 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
energy efficiency class
A++
service life
50 000 h
temperature range
от -40 до +60 C
code
1332002570
model files
model files
photometric files
сертификаты
photometric files
ies871.5 kB
jpg78.2 kB
ldt545.4 kB
сертификаты
Russian origin279.6 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20112.4 mB
Declaration of Conformity EAEU TR 037/2016541.4 kB
Fire Safety Certificate1.7 mB
