HB LED 800 D60 OPH (EXTREME) 5000K
archive
archive
HB LED 800 D60 OPH (EXTREME) 5000K
820 Wluminaire power
93000 lmlight flow
113 lm/Wenergy efficiency
code1224005200
color temperature5000
beam angleD60
weight61.3 kg
options
свернуть все
electricalconstructionalcommonilluminating
starting current
75 Astarting current pulse time, µs
240 mksrated supply voltage, alternating current
230 Vrated supply voltage, direct current
230 Vsupply voltage, alternating current
90-305 Vsupply voltage, direct current
128-431 Vluminaire power
820 Welectric shock protection
Ipower factor
> 0,96supply voltage
230 Velectrical
starting current
75 A
starting current pulse time, µs
240 mks
rated supply voltage, alternating current
230 V
rated supply voltage, direct current
230 V
supply voltage, alternating current
90-305 V
supply voltage, direct current
128-431 V
luminaire power
820 W
electric shock protection
I
power factor
> 0,96
supply voltage
230 V
constructional
ingress protection (IP)
IP65
fire safety class
П-I,II,IIa,ІІІ
material
Алюминий
weight
61.3 kg
housing color
Металлик
climatic performance
УХЛ1*
maximum cross-section of the connected cable, sq. mm
2.5
length, mm
950 mm
width, mm
685 mm
height, mm
465 mm
shock resistance (IK)
IK07/2 Дж
lamp socket
LED
number of lamps
1
ballast
Драйвер
installation length, mm
340 mm
common
ETIM class
Светильник для освещения высоких пролетов (хайбей)
warranty
60 month
temperature range
от -40 до +70 C
energy efficiency class
A+
service life, hour
50 000 h
code
1224005200
illuminating
light flow
93000 lm
flickering factor
<5%
energy efficiency
113 lm/W
beam angle
D60
color temperature
5000
light source type
LED
emission color
Белый
color rendition index (CRI)
>80
