FORWARD 150W A30 950 WH FB
FORWARD 150W A30 950 WH FB
140 Wluminaire power
15000 lmlight flow
107 lm/Wenergy efficiency
code1864001340
beam angleA30
color temperature5000 K
weight4.1 kg
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
107 lm/Wcolor rendition index (CRI)
>90light flow
15000 lmflickering factor
<1%beam angle
A30color temperature
5000 Klight source type
LEDemission color
Белыйilluminating
energy efficiency
107 lm/W
color rendition index (CRI)
>90
light flow
15000 lm
flickering factor
<1%
beam angle
A30
color temperature
5000 K
light source type
LED
emission color
Белый
electrical
luminaire power
140 W
electric shock protection
I
supply voltage
230 V
power factor
> 0,97
constructional
climatic performance
УХЛ1*
fire safety class
П-I,II,ІІІ
width
110 mm
height
235 mm
installation length
180 mm
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
length
463 mm
material
Алюминий
ingress protection (IP)
IP66
shock resistance (IK)
IK07/2 Дж
weight
4.1 kg
common
code
1864001340
warranty
60 month
energy efficiency class
A+
temperature range
от -40 до +40 C
service life
50 000 h
ETIM class
Светильник для освещения высоких пролетов (хайбей)
model files
model files
photometric files
сертификаты
photometric files
ies107 kB
jpg80.6 kB
ldt65.5 kB
сертификаты
Russian origin649.4 kB
Certificate of conformity TRTS 020/2011, TRTS 004/20111.2 mB
Declaration of Conformity EAEU TR 037/2016505.1 kB
