ATLAS ECO LED Ex/PL 15W D270 850 HG

ATLAS ECO LED Ex/PL 15W D270 850 HG
add to favorites
14 Wluminaire power
2000 lmlight flow
143 lm/Wenergy efficiency
code1585000420
color temperature5000 K
gas marking1 Ex db IIC T6 Gb
dust markingEx tb IIIC T80 C Db
beam angleD270
weight4.2 kg
  1. main page
  2. catalog
  3. by product type
  4. explosion-proof equipment
  5. explosion-proof lamps
  6. zone 1
  7. ATLAS ECO LED Ex
  8. ATLAS ECO LED Ex/PL 15W D270 850 HG
options
свернуть все
illuminatingelectricalconstructionalexplosion-proofcommon
Synchronization of flashing mode
Нет
color rendition index (CRI)
>80
light flow
2000 lm
energy efficiency
143 lm/W
flickering factor
<1%
beam angle
D270
color temperature
5000 K
light source type
LED
emission color
Белый
illuminating
Synchronization of flashing mode
Нет
color rendition index (CRI)
>80
light flow
2000 lm
energy efficiency
143 lm/W
flickering factor
<1%
beam angle
D270
color temperature
5000 K
light source type
LED
emission color
Белый
electrical
electric shock protection
I
supply voltage, direct current
127-300 V
supply voltage, alternating current
90-305 V
maximum cross-section of the connected cable
2.5 mm2
luminaire power
14 W
power factor
> 0,95
constructional
weight
4.2 kg
length
283 mm
width
150 mm
height
278 mm
installation length
42 mm
installation width
90 mm
material
Сплав алюминиевый
fire safety class
П-ІІа
climatic performance
УХЛ1
shock resistance (IK)
IK08/7 Дж
housing color
Серый
explosion-proof
gas marking
1 Ex db IIC T6 Gb
dust marking
Ex tb IIIC T80 C Db
gas explosion-proof (type)
Ex db
gas explosion-proof (zones)
1
gas explosion-proof (groups of equipment)
IIC
T6 - temperature class
T6
common
code
1585000420
warranty
36 month
temperature range
от -60 до +55 C
energy efficiency class
A++
service life
50 000 h
ETIM class
Светильник взрывобезопасный/взрывозащищенный стационарный (фиксиров. установки)
model files
model files
photometric files
ies107.1 kB
jpg100.9 kB
ldt87 kB
сертификаты
Certificate of Russian maritime register of shipping1.5 mB
Certificate of conformity TRTS 012/2011412.2 kB
Declaration of Conformity TRTS 020/2011201.4 kB
Certificate of seismic resistance834.7 kB
Declaration of Conformity EAEU TR 037/2016197.5 kB
photometric files
ies107.1 kB
jpg100.9 kB
ldt87 kB
сертификаты
Certificate of Russian maritime register of shipping1.5 mB
Certificate of conformity TRTS 012/2011412.2 kB
Declaration of Conformity TRTS 020/2011201.4 kB
Certificate of seismic resistance834.7 kB
Declaration of Conformity EAEU TR 037/2016197.5 kB
