Area LED 75 W PLC 5000K
Area LED 75 W PLC 5000K
70 Wlamp power, W
220 Vsupply voltage
5000 color temperature
code1054000200
electric shock protectionI
weight13.2 kg
options
свернуть все
electricalconstructionalcommonilluminating
starting current
55 Astarting current pulse time, µs
200 mksrated supply voltage, alternating current
220 Vrated supply voltage, direct current
220 Vsupply voltage, alternating current
90-305 Vsupply voltage, direct current
127-420 Vluminaire power
70 Welectric shock protection
Ilamp power, W
70 Wsupply voltage
220 Velectrical
starting current
55 A
starting current pulse time, µs
200 mks
rated supply voltage, alternating current
220 V
rated supply voltage, direct current
220 V
supply voltage, alternating current
90-305 V
supply voltage, direct current
127-420 V
luminaire power
70 W
electric shock protection
I
lamp power, W
70 W
supply voltage
220 V
constructional
ingress protection (IP)
IP66
fire safety class
П-I,II,ІІІ
material
Алюминий
housing color
Металлик
climatic performance
УХЛ1
maximum cross-section of the connected cable, sq. mm
2.5
weight
13.2 kg
length, mm
510 mm
width, mm
265 mm
height, mm
92 mm
common
ETIM class
Светильник для освещения улиц и площадей
temperature range
от -60 до +40 C
energy efficiency class
A+
code
1054000200
warranty
60 month
service life, hour
50 000 h
illuminating
color temperature
5000
model files
model files
CAD/BIM files
documents
сертификаты
CAD/BIM files
CAD model 3DS531.9 kB
model 3dMax3.1 mB
documents
passport3.3 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/2011292.2 kB
Declaration of Conformity EAEU TR 037/2016291.7 kB
