ARCTIC.OPL ECO LED 1500 TH 4000K /E/

model is discontinued
model is discontinued
ARCTIC.OPL ECO LED 1500 TH 4000K /E/
add to favorites
44 Wluminaire power
4500 lmlight flow
102 lm/Wenergy efficiency
code1997028510
color temperature4000 K
beam angleD120
performance factor100
weight3.2 kg
  1. main page
  2. catalog
  3. by product type
  4. interior lighting
  5. ceiling
  6. IP protected
  7. ARCTIC.OPL ECO LED TH
  8. ARCTIC.OPL ECO LED 1500 TH 4000K /E/
options
свернуть все
illuminatingelectricalconstructionalcommon
energy efficiency
102 lm/W
color rendition index (CRI)
>80
light flow
4500 lm
flickering factor
<5%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
illuminating
energy efficiency
102 lm/W
color rendition index (CRI)
>80
light flow
4500 lm
flickering factor
<5%
beam angle
D120
color temperature
4000 K
light source type
LED
emission color
Белый
electrical
power factor
> 0,98
luminaire power
44 W
electric shock protection
II
supply voltage
230 V
maximum cross-section of the connected cable
2.5 mm2
constructional
length
1578 mm
width
96 mm
height
110 mm
installation length
1234 mm
weight
3.2 kg
ingress protection (IP)
IP65
shock resistance (IK)
IK02/0,2 Дж
climatic performance
УХЛ2
fire safety class
П-ІІ
material
Пластик
housing color
Белый
lamp socket
LED
number of lamps
1
ballast
Драйвер
common
temperature range
от -40 до +40 C
service life
50 000 h
ETIM class
Настенно-потолочный светильник
warranty
60 month
energy efficiency class
A+
code
1997028510
model files
model files
CAD/BIM files
model 3dMax2 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
CAD/BIM files
model 3dMax2 mB
сертификаты
Certificate of conformity TRTS 020/2011, TRTS 004/20113.2 mB
Declaration of Conformity EAEU TR 037/2016658.3 kB
Fire Safety Certificate2.5 mB
